15 KiloVolt - Ampere Vertical CNC Machine VMC850B With BT40 150mm Spindle

15 KiloVolt - Ampere Vertical CNC Machine VMC850B With BT40 150mm Spindle
15 KiloVolt - Ampere Vertical CNC Machine VMC850B With BT40 150mm Spindle

Large Image :  15 KiloVolt - Ampere Vertical CNC Machine VMC850B With BT40 150mm Spindle

Product Details:
Place of Origin: CHINA
Brand Name: JOINT
Certification: ISO 9001:2015
Model Number: VMC850B
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Delivery Time: NEGOTIATION
Payment Terms: TT/LC/DA/DP
Supply Ability: 1000 SETS/YEAR
Detailed Product Description
Name: Vertical CNC Machine VMC850B 3 Axis Travel: 800*500*500mm
Spindle Taper: BT40 45° Spindle Diameter: 150mm
Rapid Feed: 15/15/12 M/min 3 Axis Motor: 1.4/1.4/1.8 Kw
Total Power: 15KVA Net Weight: 5000KG
High Light:

vmc cnc milling machine


cnc moulding machine

15KVA Total Power Vertical CNC Machine VMC850B BT40 150mm Spindle



Product features:


1. VMC850B hardway cnc machine is with cross slide structure, herringbone column
2. There are strengthing ribs and supporting plate inside bed,column,slider, table and spindle box.
3. X,Y,Z rectangular guide ways with high stability
4. Motors and lead screws are direct connection.
5. Main parts are Taiwan famous brand, such as spindle, magazine, ball screws etc.
6. The machine is with full protection.



Company advantage:


1. We are the biggest manufacturer in our city. Our products includes milling machine, drilling machines, cnc machines etc.
2. We attend many home and abroad exhibitions every year. In China, we attend Beijing or Shanghai exhibition, Canton fair.
In abroad, we attend EMO, Russia exhibition, Brazil exhibition etc.
3. Our market covers more than 70 ountries and regions, especially Europe & America market.
4. We have got many certifications, such as CE,ISO etc.



Specification Of Vertical machine center VMC850B


Model Unit VMC-850B
Travel X axis mm 800
Y axis mm 500
Z axis mm 550
Distance between spindle and table mm 105-655
Working table Table size mm 1050*500
Max. Load of table Kg 600
T slot Pcs-mm-mm 5-18-90
Positioning accuracy X/Y/Z axis mm 0.008/0.008/0.008
Repeated positioning accuracy X/Y/Z axis mm 0.007/0.007/0.007
Spindle Spindle rotation speed Rpm 8000
Spindle taper   BT40
Diameter mm Φ150
Rivet model   BT40 45°
Rapid feed X/Y/Z axis m/min 15/15/12
Cutting feed X/Y/Z axis m/min 8
Tool magazine Umbrella type Size Tools 20
Too changing time (T-T) Sec 6
Max. diameter/ length/weight of tool mm 100/200/8
Max tool diameter (no tool adjacent) mm 180
Arm type Size Tools 24
Tool changing time (T-T) sec 3.5s
Max. diameter/ /length/weight of tool mm 80/200/8
Max tool diameter (no tool adjacent) mm 150
Total capacity of electric KVA 15
Weight of machine



Dimension mm 2500*2270*2550



Standard Accessories:


Fanuc Controller system


8000Rpm spindle


Full enclosed cover


Spindle encoder position system


Three axis inner encoder feedback system


Auto lubrication system


Pneumatic system


RS 232 Interface


Operation unit


RS232 Interface +working light


Tool and tool box



Optional accessories:


Siemens controller or other controller system


Spindle oil coolant


Heat exchanger


Umbrella type tool magazine


Arm type tool magazine


Screw type auto conveyor


Chain type tool magazine


4 Axis rotary table


Ring spray spindle
