Product Details:
Payment & Shipping Terms:
|
| Y/Z Axis Travel: | 500/500mm | Spindle Sleeve Travel: | 140mm |
|---|---|---|---|
| Dimension: | 2300*2000*2900mm | Spindle Power: | 5HP/NT40 |
| Distance From Spindle Nose To Table: | 690mm | Swing Angel: | ±45°（forward And Backward Direction） |
| Highlight: | Ball Screw Turret Milling Machine,Draw Bar Turret Milling Machine,5HP Spindle Vertical Milling Machine |
||
Our Key Advantages:
1. Machine fuselage is strengthened to make sure the stability of machine.
2. 8VA bearing is Japan famous brand NSK P4 level bearing.
3. Its spindle tolerance can high up to 0.002mm.
4.We have manufactured it since 1995.
And customers feedback are all good, no matter domestic or oversea customers.
5. This size is our biggest size can meet your need.
.
Parameters Sheet:
| Model | 8VA | |||
| Table size | mm | 1524*360*99 | ||
| Travel | X axis | mm | 1150 | |
| Y axis | mm | 500 | ||
| Z axis | mm | 500 | ||
| Travel of spindle quill | mm | 140 | ||
| Maximum distance from spindle nose to table | mm | 690 | ||
| Spindle | Rotation speed (Step speed milling head) |
50HZ | rpm | 60-3000 (10 grade) |
| 60HZ | rpm | 70-3600 (10 grade) | ||
| Rotation speed (Variable speed milling head) |
50HZ | rpm | 60-3250 | |
| 60HZ | rpm | 70-3900 | ||
| Rotation speed (Inverter speed milling head) |
50HZ | rpm | 0-4200 | |
| 60HZ | rpm | 0-4200 | ||
| Taper | NT40 | |||
| Rated power | HP | 5HP (7.5HP Optional) | ||
| Tilt angle | Forward and Backward | 0° (±45° Optional) | ||
| Left and Right | ±90° | |||
| Dimension | mm | 2300*2000*2900 | ||
| Net weight | kg | 2900 | ||
Standard Accessories:
1. Taiwan original step speed milling head
2. Working light
3. Draw bar
4. Maual oil pump
5. Manual operation
6. Guide way cover
7. Tool and tool box
8. Clamping kits
9. Milling chuck (7pcs)
Optional accessories:
1. Water pump
2. M12 clamping kits
3. 6' vise
4. X axisp ower feed or Y axis power feed or Z axis elevating motor
5. X/Y two axis/ X/Y/Z three axis DRO
water tray vise Z axis elevating motor
Guide protection cover
