D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design

China D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design supplier
D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design supplier D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design supplier D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design supplier

Large Image :  D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design

Product Details:

Place of Origin: CHINA
Brand Name: JOINT
Certification: ISO 9001:2015
Model Number: CKI6150

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: NEGOTIATION
Packaging Details: WOODEN PALLTES / WOODEN CASE
Delivery Time: NEGOTIATION
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SETS/YEAR
Contact Now
Detailed Product Description
Name: Flat Bed CNC Lathe Machine CKI6150 Spindle Speed: 3 Grades Gear Speed
Max Length Of Workpiece: 3000mm Through Spindle Hole: 82mm
Max Swing Over Table: 500mm Max Swing Over Carriage: 290mm
Spindle Taper: D8/250 Travel Of Sleeve: 150mm

3000mm workpiece length Flat bed CNC Lathe Machine CKI6150-3000

D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design

1. A high strength ,widening the carriage ,suitable for heavy cutting
2. Four station electric tool post
3. Structure of spindle box: 3 grades gear speed
4. Standard configuration: manual chuck
5. Optional configuration: hydraulic chuck

D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design
D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design


1. Machine body guide way are quenched for better resistance of abrasion, and increased stability and

    accuracy.
2. 6136, 6140 machine employ intergrated body structure, and extra wide guide way with better vibration

    resistance.
3. Spindle, saddle adopt special structure and technology, which increase precision, stability and accuracy.
4. Models above 6150 adopt gear box transmission design, and are equipped with inverter spindle motor

    which can enable strong cutting force with 3-level gear speed, and change rotation speed by controller

    system at each speed level.
5. Optional control system: GSK Control system, KND control system and Fanuc mate control system.

D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design


ItemUnitCKI-6150
Max swing over tablemm500
Max swing diameter over carriagemm290
Spindle head D8/250
Max processing lengthmm3000
X axis Travelmm295
Z axis Travelmm800
Spindle through hole diametermm82
Spindle motorkw7.5
Spindle rotation speedrpmSpindle 3 grades gear box:
45-180, 180-750, 600-1600r/min
Servo motor connection type Direct connection
X axis rapid feedm/min6
Z axis rapid feedm/min8
Tool width*heightmm20*20
Turret center heightmm≤145
Tailstock Shaft diameter*travelmmφ75*120
Tailstock taper MT5
Positioning accuracymm0.01
Powerkw/h10
Dimensionmm2490*1420*1600
Net weightkg2300


D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design


1GSK 980TDi Controller system with servo motor and driver74 position electronic turret
2Working light83 jaw chuck
3Spindle9Leveling pad
4Auto lubrication system10Manual tailstock
5Machine cover11Tools and toolbox
6Operation unit12Technical documents


D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design
 D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed DesignD8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design
 D8/250 Spindle Taper Horizontal CNC Lathe Machine 3 Grades Gear Speed Design
