280mm Electrode Head 5KVA Electric Discharge Machine

280mm Electrode Head 5KVA Electric Discharge Machine
280mm Electrode Head 5KVA Electric Discharge Machine 280mm Electrode Head 5KVA Electric Discharge Machine 280mm Electrode Head 5KVA Electric Discharge Machine

Large Image :  280mm Electrode Head 5KVA Electric Discharge Machine

Product Details:

Place of Origin: CHINA
Brand Name: JOINT
Certification: ISO 9001:2015
Model Number: ZNC-450

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: NEGOTIATION
Packaging Details: WOODEN PALLTES / WOODEN CASE
Delivery Time: NEGOTIATION
Payment Terms: TT/LC/DA/DP
Supply Ability: 1000 SETS/YEAR
Detailed Product Description
X/Y/Z Axis Travel: 455*360*200 Mm Electrode Head: 280mm
Max Load Of ELECTRODE HEAD: 120kgs Net Weight: 1500kg
Diemension: 2050*2530*2400mm Filter Container Cube: 400L
High Light:

5KVA Electric Discharge Machine

,

700*400mm Table Electric Discharge Machine

,

280mm Electrode Head EDM Machine

ZNC-450 Electrical discharge vertical machine erosion die mould easy operation





280mm Electrode Head 5KVA Electric Discharge Machine 0



EDM machine

Model ZNC450
Size of oil container  620*860*1850mm
Table size 700*400mm
X axis travel 455mm
Y axis travel 360mm
Z axis travel 200mm
Electrode head 280mm
Max distance from the electrode head to table 480mm
Max load of electrode head 120kg
Max load of table 1200kg
Dimension 2050*2530*2400mm
Net weight 1500kg
Filter container cube 460L



Electric cabinet

Model ZNC Machine
Control mode and axis No. NC with close circuit/single z axis control
Min setting value 0.005(0.001)mm
Max setting value 9999.995(9999.9999)mm
Coordination system INC  ABS
Screen 15'' FTT
Control system Industrial PC
Moving velocity of controller 0.005mm per unit*1, *5, *10
Procedure in store 0-999 groups
Max current for processing 50A
Input rated power 5KVA
Max cutting processing speed 360mm²/min
Consumption of electrode head <0.2%
Best surface rough 0.25
Dimension 620*860*1850mm
Net weight 210kg



Products Character:



1. Full size machine could meet with mold processing requirement.



2. System stability and durability, high reliability, greatly improve the precision and quality of the mold.



3. All key parts are from Taiwan and Japanese top brands.





 280mm Electrode Head 5KVA Electric Discharge Machine 1

280mm Electrode Head 5KVA Electric Discharge Machine 2

280mm Electrode Head 5KVA Electric Discharge Machine 3
